Product model

DSJ-ZWAP1A1

Product description

Intelligent law enforcement recorder P1 is based on the needs of mobile law enforcement, fully integrated mobile communication, AI intelligent analysis, cloud computing, big data and other new generation of information technology, independently developed a new generation of full-function high-end intelligent law enforcement terminal, with industry-leading product functions. It can meet the whole police and other industries of video and audio forensics, visual command and dispatch, police service processing, artificial intelligence analysis and other diversified scenarios.

Product characteristics

l Full Netcom 4G intelligent law enforcement recorder, 8 core 64-bit CPU, 2G running memory, H.265 coding

l Master and deputy dual photography, main photography 48 million high-definition recording, support 1080P high-definition wireless real-time image transmission

l Support SIM card and TF card encryption mode to enter the public security network gate; Supports remote control of devices from the cloud to achieve data security control

l One-button PTT cluster intercom, can achieve grouping, cross-group, strong plug and other functions, clear call without noise

l Meet the GA/T 947-2015 line standard, can be connected to GB/T 28181-2016 national standard

l Type-C port can be used for external HD cameras and earphones to meet the requirements of more scenarios

l Deep customization based on Android system, supporting the selection of AI intelligent recognition function, supporting customized real-time translation/fingerprint authentication and industry application APP function customization

Basic parameter

Operating system

Android

CPU

8-core 64-bit chip, 2.3G main frequency, 16nm low power process

memory

2GB(RAM), 32G(ROM)

Display screen

2.4 "IPS full view high-light capacitive touch display, sunshine mode

camera

SONY high-performance photosensitive chip, master and deputy dual camera

Digital encryption

support

Finger print

Fingerprint playback Authentication (Optional)

Data interface

Type-C USB 3.0 and Mrico USB interface/Bluetooth 4.0

TF card

Supports a maximum of 512 GB

communication

linear

4G full Netcom, 7 mode 13 frequency, support telecom, mobile, Unicom

Network standard

LTE FDD/TDD R12 Cat-7 with 2CA DL/ 2CA UL   DC-HSPA+, TD-SCDMA, EDGE CDMA2000 1x/EVDO Rev. A (SRLTE)

WIFI function

Built-in WIFI function, can also support 802.11B/G/N/AC

positioning

Support Beidou /GPS/ Beidou +GPS

NFC

support

video

Video codec

H.265/H.264 encoding

Code stream

Dual stream

Video resolution

2K /1080P /720P/480P, MPEG4 format

Photo resolution

48 million effective pixels saved in JPG format

walkie-talkie

flop

High-power amplifier to meet public network intercom requirements

Dual digital noise reduction

Noise-cancelling digital silicon MIC for clearer call/intercom sound quality

Cluster intercom

Supports force-insert, grouping, and cross-group modes

Video intercom

Supports 1080P/720P high-fidelity video calls

Brain power

Image recognition

support

Translation function

Support voice/photo/text real-time translation (optional)

other

Press the key

Power button/Mark button /PTT button /SOS button/Photo button/Video button/recording button/Multi-function button /HOME button

Pilot lamp

Support red and blue flash/white light/laser indication/infrared night vision/prompt light

Class of protection

IP68, free fall of 2 meters

Electric cell

3050mAh removable large capacity battery

External equipment

Support external HD digital camera, external high fidelity intercom headset

Dimensional weight

90*58*27 (mm), bare weight 150g (without back clip)

Packing list

Host *1, back clip *1, power adapter *1, USB cable *1, manual *1
