Product model

ZCS-ZWAZ2

System software

Operating system

Win7 64-bit (optional win10 64-bit)

Acquisition software

Zhongwei security single police law enforcement video audio recorder data management system

Hardware configuration

Display element

10.1-inch display, resolution 1280*800 (maximum support 1920*1080)

Touch module

Capacitive touch screen

The main chipset

Dual-core CPU Intel chipset

Memory capacity

4G DDR 1600/1333/1066 MHz, (optional 8~16G)

System disk

60G SSD

Storage hard disk

Each disk supports a maximum capacity of 8TB

Acquisition interface

Mini/Micro/typeC- USB x 10 collection ports

Application function

Collection management

Logger registration binding management

Supports resumable data collection process

Dynamic display of collection progress and charging status

The acquisition device corresponds to the position displayed on the screen

The device collects data automatically and the quantity of data collected at the same time can be customized

Comply with the certification rules of the public safety industry standard interface

Data processing

Video files without compression in original image quality

Automatic sorting (by file type/resolution or date)

Automatically upload to the specified server

Upload policies can be configured (time range/destination address/file type/network bandwidth, etc.)

When the recorder is calibrated automatically, the acquisition completion status is checked automatically, and the data is cleared automatically

Storage management

Storage policy management (storage path/storage file type/compression method, etc.)

Storage space management (Clearing mode, early warning mode, expansion mode, backup mode, etc.)

Memory status display

Distributed evidence download, view

Data security

Unauthorized users do not have data operation rights

Data synchronization

Active + passive interaction with management platform, bidirectional database synchronous fault tolerance mechanism

Authority management

Unlimited level permission recursive management

Job appraisal

Personnel assessment, unit assessment

Site management

Multi-level workstation site management

Log management

Operation logging

compatibility

Compatible with all law enforcement recorders in accordance with the Ministry of Public Security (GA/T947-2015) standards

Main interface

On-off key

Physical keys *1

Network interface

RJ45*1

Data interface

USB-A female *2

Physical characteristics

Power source

AC IN: 100~240V; 50~60Hz overvoltage protection, over current protection, over power protection, short circuit protection

Power dissipation

≤84W

Operating temperature

- 10 ℃ ~ 55 ℃

Working humidity

< 90%

Overall dimensions (mm)

Width 436mm* Depth 298mm* height 95mm

Net product weight

7.8 kg
