Product model

DSJ-ZWAP3A1

Product characteristics

l 012 Products of agreement

4G full Netcom, 8-core 64-bit CPU, 4G large running memory, H.265 coding

l Master and deputy dual photography, main photography 52 million, support 4K/2K/1080P HD wireless real-time image transmission

l Support SIM card and TF card encryption mode to enter the public security network gate; Supports remote control of devices from the cloud to achieve data security control

l One-button PTT cluster intercom, can achieve grouping, cross-group, strong plug and other functions, clear call without noise

l Meet the GA/T 947-2015 line standard, can be connected to GB/T 28181-2016 national standard

l Type-C port can be used for external HD cameras and earphones to meet the requirements of more scenarios

l Deep customization based on Android system, supporting the selection of AI intelligent recognition function, supporting customized real-time translation/fingerprint authentication and industry application APP function customization

The base parameter

Operating system

Android

CPU

8-core 64-bit chip, 2.3G main frequency, 16nm low power process

memory

4GB(RAM), 64G(ROM)

Display screen

2.4 "IPS full view high-light capacitive touch display, sunshine mode

camera

SONY high-performance photosensitive chip, master and deputy dual camera

Finger print

Fingerprint playback Authentication (Optional)

Digital encryption

support

Data interface

Type-C and Mrico USB interface/Bluetooth 4.0

store

The standard configuration is 64 GB. The maximum value is 512 GB

Video and audio

Photo resolution

52 million effective pixels saved in JPG format

Video resolution

4K/2K/1080P/720P, MPEG4 format

Horizontal field Angle

Greater than 100°

Video codec

H.265/H.264 encoding, dual stream

Wireless transmission function

linear

4G full netcom wireless transmission; Built-in WIFI, support 4G public network and private network transmission

Real-time image transmission

Support 4K/2K/1080P/720P HD wireless video real-time transmission, video and audio HD, smooth, stable

Video intercom

Support 1080P/720P high fidelity two-way video intercom between devices and devices, devices and platforms

Cluster intercom

Supports force-insert, grouping, and cross-group modes

Police correlation

In the alarm mode, the audio and video are automatically marked and the alarm number is superimposed, and the files are automatically connected to the alarm database

Location tracking

Built-in Beidou /GPS/GPS+ Beidou mixed mode positioning, real-time positioning

SOS call

Support law enforcement recorder one key SOS call platform

Intelligent function

Image recognition

Support face/license plate recognition early warning (optional)

Translation function

Support voice/photo/text real-time translation (optional)

APP function

Mobile APP to achieve remote monitoring/monitoring/intercom/track tracking/create electronic fence/command and other functions (optional)

other

Class of protection

IP67, free fall of 2 meters

Electric cell

3050mAh removable large capacity battery

External equipment

Support external HD digital camera, support external high fidelity intercom headset

Dimensional weight

90*58*27 (mm), bare weight 150g (without back clip)

Packing list

Host *1, back clip *1, power adapter *1, USB cable *1, manual *1
