The Kun'an Series Large Capacity Storage Control Center focuses on deep data application, and is based on the design and development concept of high performance, high reliability, and high integration. It provides users with large capacity storage space and rapid deployment solutions for law enforcement data such as video, audio, and images.
Technical specification
Product model | ZWA-CS2424 |
Chassis specification | 4U Dual server with 24 disks |
CPU | Configure two Intel Xeon Silver 4210 processors, 2.20 GHz, 13.75 MB, 10C, 20T, and 85W |
System memory | 16 DIMM slots for supporting 2400 MHZ, 2666 MHZ, and 2933MHz DDR4 RDIMMs (up to 4TB) Intel Optane DIMMs are optional |
Hard disk storage | Supports 24 3.5 "SATA/SAS/ SSDS, optional 2 rear/built-in 2.5-inch hot swappable (Supports 2 NVME SSDS, built-in) |
Storage type | SATA, SAS, SSD |
Raid type | Configure an 8-port 1GB cache RAID card, supporting SATA RAID0, 1, 10, 5, etc. Optional Support for SAS RAID0, 1, 10, 5, 50, 6, and 60, RAID 512MB/1GB/2GB Cache, and cache power failure protection |
network | Two Intel i210 GE network ports are integrated. Optional external Gigabit and 10-Gigabit network cards |
Other ports | USB3.0 ports: 2 (2 at the rear) USB2.0 interface: 4 (2 rear, 2 front) VGA port: 1 (1 at the rear) Management network port: 1 (one at the rear) |
Power source | Standard 800W 1+1 hot-swappable redundant power supply, |
Support operating system | Windows Server 2016 Red Hat* Enterprise Advanced Server 7.3 Suse Linux Enterprise Server 11 SP4 |
